RTH 5.21 Smart

  • lifting weight4,999 kg
  • lift height20.70 m

magni rotating telehandler 5 21 smartThe RTH 5.21 is a simple yet high-performance rotating telescopic handler. It can lift loads up to a height of 21 m, and is equipped with pivoting stabilisers to guarantee stability and safety during all operational manoeuvres. It is also equipped with a safe load indicator to inform the driver of the risk of overloading the machine during use, and features three steering modes. It is compatible with a wide range of accessories thanks to its RFID system which allows automatic recognition of attachments and creation of the corresponding load charts. This telescopic handler is the ideal solution to a long list of requirements in the construction and production sectors. The performance of the SMART range, improved by its 3000 mm wheelbase, offers significant manoeuvrability benefits. Its compact structure is supported by an impressive turning radius, allowing it to move around the tightest spaces.

Technical Features

  • Stabilizers: pivoting
  • Lifting capacity: 4,999 kg
  • Capacity at maximum height: 2,500 kg
  • Lifting height: 20.70 m
  • Reach: 17.70 m
  • Engine: Deutz TCD 3.6 L4 – stage IV
  • Rated power: 100 kW – 136 cv
  • Number of gears: ‘2/2
  • Hydraulic system: Load Sensing 350 bar
  • Length: 6.57 m
  • Width: 2.50 m
  • Ground clearance: 329.00 mm
  • Empty weight: 16,500 kg
  • Travel speed: 40.00 km/h
  • Rotation: 360 °
  • Climate control as standard: Sì
  • Automatic accessory recognition: Yes

Regulations

  • CE certificate
  • EN 1459-2: concerning standards for slewing variable-reach trucks
  • EN 280: concerning standards for mobile elevating work platforms
  • EN 13000: concerning standards for hydraulic cranes
  • FOPS/ROPS
  • UE 2016/1628: concerning engine emissions standards
