HTH 27.11

  • lifting weight27,000 kg
  • lift height10.85 m

Heavy Lift Telehandlers 27 11The HTH 27.11 telescopic handler is ideal for moving large, bulky loads in complete safety.

Able to lift up to 27 tonnes, it is compatible with a wide range of accessories, making it extremely versatile. Equipped with an RFID system which provides automatic recognition of the various attachments used, this telescopic handler is able to meet a wide range of applications in heavy industry and mining. Its four-wheel drive system, three manoeuvring modes and high ground clearance makes it highly manoeuvrable on all terrains. Its 204 hp engine and hydrostatic transmission offer power, manoeuvrability and precision when moving loads.

The comfort and 360° visibility offered by Magni’s patented cab allow the operator to work under the optimum conditions, and help improve safety during delicate movements. It can move large blocks of marble or stone in quarries, or handle materials such as steel bars, rails or other metal structures. It is the ideal machine for maintenance of mining equipment, such as changing rails, replacing hammers or moving conveyor belts.

Technical Features

  • Lifting capacity: 27,000 kg
  • Capacity at maximum height: 14,500 kg
  • Lifting height: 10.85 m
  • Reach: 6.60 m
  • Engine: Mercedes OM 934 LA Stage IV
  • Rated power: 150 kW – 204 cv
  • Number of gears: 2/2
  • Hydraulic system: Load Sensing 350 bar
  • Length: 7,550 mm
  • Width: 2,975 mm
  • Ground clearance: 530 mm
  • Unladen weight: 35,500 kg
  • Speed of movement: 25 km/h
  • Climate control as standard: Yes
  • Automatic accessory recognition: Yes

Regulations

  • CE certificate
  • EN 1459-2: concerning standards for slewing variable-reach trucks
  • EN 13000: concerning standards for hydraulic cranes
  • FOPS/ROPS
  • UE 2016/1628: concerning engine emissions standards
