TH 5.24

  • lifting weight5,000 kg
  • lift height24 m
  • stabilizer legs
  • joystick control

The TH 5.24 is a telescopic handler suited to demanding sites. It can reach 24 m in height in complete safety, even on rough terrain thanks to its automatic levelling – which acts on both the wheels and stabilisers – and its four-wheel drive system. The hydrostatic transmission offers precision and manoeuvrability. It is compatible with a huge range of accessories, and is equipped with the RFID system which provides automatic recognition of attachments and creation of the relative load charts. It is equipped with a side shift function, allowing the rear section of the chassis along with the telescopic boom to move laterally with respect to the machine’s longitudinal axis in order to correct the position of the load without having to move the vehicle. As this model is EN 13000 compliant, it can be equipped with a winch and thus work with suspended loads.

Technical Features

  • Lifting capacity: 4,999 kg
  • Lifting height: 23.90 m
  • Engine: Deutz TCD 3.6 L4 – stage IV
  • Rated power: 100 kW – 134 cv a 2.200 giri/min
  • Number of gears: 2/2
  • Hydraulic system: Load Sensing 350 bar
  • Length: 6.75 m
  • Width: 2.50 m
  • Unladen weight: 15,500 kg
  • Travel speed: 40 km/h
  • Climate control as standard: Yes
  • Automatic accessory recognition: Yes

Regulations

  • CE certificate
  • EN 1459-2: concerning standards for slewing variable-reach trucks
  • EN 280: concerning standards for mobile elevating work platforms
  • EN 13000: concerning standards for hydraulic cranes
  • FOPS/ROPS
  • UE 2016/1628: concerning engine emissions standards
