HTH 50.14

  • lifting weight50,000 kg
  • lift height14.00 m

Heavy Lift Telehandlers 50 14The HTH 50.14 telescopic handler is ideal for moving large, bulky loads in complete safety. Able to lift up to 50 tonnes, it is compatible with a wide range of accessories, making it extremely versatile. Equipped with an RFID system which provides automatic recognition of the various attachments used, this telescopic handler is able to meet a wide range of applications in heavy industry and mining. Its four-wheel drive system, three manoeuvring modes and high ground clearance makes it highly manoeuvrable on all terrain types. Its 350 hp engine and hydrostatic transmission offer power, manoeuvrability and precision when moving loads. The comfort and 360° view offered by Magni’s patented cab allow the operator to work under the optimum conditions, and help improve safety during delicate movements. It can move large blocks of marble or stone in quarries, or handle materials such as steel bars, rails or other metal structures. It is the ideal machine for maintenance of mining equipment, such as changing rails, replacing hammers or moving conveyor belts.

Technical Features

  • Lifting capacity: 50,000 kg
  • Capacity at maximum height: 28,000 kg
  • Lifting height: 14.00 m
  • Reach: 8.00 m
  • Engine: Mercedes OM 936 LA Stage IV
  • Rated power: 260 kW – 350 cv
  • Number of gears: 3/3
  • Hydraulic system: Load Sensing 350 bar
  • Length: 10,705 mm
  • Width: 3,203 mm
  • Ground clearance: 620.00 mm
  • Unladen weight: 65,000 kg
  • Speed of movement: 20.00 Km/h
  • Climate control as standard: Yes
  • Automatic accessory recognition: Yes

Regulations

  • CE certificate
  • EN 1459-2: concerning standards for slewing variable-reach trucks
  • EN 13000: concerning standards for hydraulic cranes
  • FOPS/ROPS
  • UE 2016/1628: concerning engine emissions standards
