RTH 5.18

  • lifting weight5 Ton
  • lift height18 m
  • engine hp134 hp
  • stabilizer legs
  • joystick control

magni rotating telehandler 5 18 smartThe RTH 5.18 model is a rotating telehandler ideal for both construction sites and rental Company. Compact and multifunctional, it is compatible with a wide range of accessories, thanks also to the RFID system that allows automatic recognition and the consequent creation of relative load diagrams, this lift is able to respond to countless applications in the building sector and industry. It is equipped with pivoting stabilizers with a good supporting surface, a load status control system that detects the risks of overloading the machine and three types of steering. The performance of the Smart line, underlined by a wheelbase of 3000 mm, ensures advantageous performance on tires – at the same time the reduced frame is assisted by a wide turning radius, which allows agile maneuvers even in small spaces.

Technical Features

  • Stabilizers: pivoting
  • Lifting capacity: 4,999 kg
  • Capacity at maximum height: 3.000 kg
  • Lifting height: 17,56 m
  • Reach: 14,26 m
  • Engine: Deutz TCD 3.6 L4 – stage IV
  • Rated power: 100 kW – 134 cv
  • Number of gears: 2/2
  • Hydraulic system: Load Sensing 350 bar
  • Length: 6.69 m
  • Width: 2,50 m
  • Ground clearance: 329 mm
  • Empty weight: 15.630 kg
  • Travel speed: 40 km/h
  • Rotation: 360 °
  • Climate control as standard: Yes
  • Automatic accessory recognition: Yes


  • CE certificate
  • EN 1459-2: concerning standards for slewing variable-reach trucks
  • EN 280: concerning standards for mobile elevating work platforms
  • EN 13000: concerning standards for hydraulic cranes
  • UE 2016/1628: concerning engine emissions standards

INSTOCK RTH 5.18 with blue tooth remote drive -Enquire
