RTH 5.25 Smart

  • lifting weight4,999 kg
  • lift height24.60 m

magni rotating telehandler 5 25 smartThe RTH 5.25 is a compact yet high-performance rotating telescopic handler. It can lift loads up to a height of 25 m, and is equipped with pivoting stabilisers to guarantee stability and safety during all manoeuvres. It is compatible with a huge range of accessories, thanks also to the RFID system which provides automatic recognition and creation of the relative load charts; this telescopic handler is able to meet a wide range of applications in construction and industry. The performance of the Smart range, highlighted by a 3,000 mm wheelbase, guarantees advantageous performance on tyres, while at the same time the compact chassis is assisted by an impressive turning radius to provide manoeuvrability in tight spaces.

Technical Features

  • Stabilizers: pivoting
  • Lifting capacity: 4,999 kg
  • Capacity at maximum height: 2,000 kg
  • Lifting height: 24.60 m
  • Reach: 19.00 m
  • Engine: Deutz TCD 3.6 L4 – stage IV
  • Rated power: 100 kW – 136 cv
  • Number of gears: 2/2
  • Hydraulic system: Load Sensing 350 bar
  • Length: 7.62 m
  • Width: 2.50 m
  • Ground clearance: 329.00 mm
  • Empty weight: 17,230 kg
  • Travel speed: 40,00 Km/h
  • Rotation: 360°
  • Climate control as standard: Sì
  • Automatic accessory recognition: Yes

Regulations

  • CE certificate
  • EN 1459-2: concerning standards for slewing variable-reach trucks
  • EN 280: concerning standards for mobile elevating work platforms
  • EN 13000: concerning standards for hydraulic cranes
  • FOPS/ROPS
  • UE 2016/1628: concerning engine emissions standards

Want more information on RTH 5.25 Smart?

This multi-page PDF will give you all the information you need including performance and technical specifications.

Please provide your email address to download the PDF.
